| 加工定制 | 是 |
|---|---|
| 功率 | 0.37（kw） |
| 外形尺寸 | 2000*850*2200 |
| 灌装头数 | 12 |
| 灌装量 | 100-5000（ml） |
| 适用瓶高 | 100-360（mm） |
| 适用瓶径 | 50-160（mm） |
| 生产能力 | 50（罐/分钟） |
| 灌装精度 | 0.5（%） |
| 包装类型 | 桶 |
| 工作原理 | 常压 |
| 适用对象 | 果汁饮料,酒类饮料,矿泉水、纯净水,酸奶,鲜奶,油类,化妆品类,清洁、洗涤用品,药水,液体酒精,其他 |
| 适用行业 | 餐饮,食品,日化,医药,**,化工,其他 |
| 物料类型 | 液体 |
| 自动化程度 | 全自动 |
| 售后服务 | 保修一年 |
| 品牌 | 四信机械 |
| 型号 | ZHGA型 |
该机是一种由微电脑（PLC）可编程控制，光电传感，气动执行于一体的高新技术灌装设备。本机型专用于食品类，如：白酒、酱油、醋、调味品、植物油、糖浆、矿泉水等可食性液体以及农药化工类液体的灌装。灌装计量**，无气泡、无滴漏。可适用于50-1000ml各种瓶型（包括异型瓶）的灌装。
一、先进的设计
该机适用于不同规格容器的灌装，可在数分钟内切换灌装规格。
灌装周期短、生产能力高。
更换灌装规格无需增添备件，只需作调整即可完成。
用户可根据自己的生产能力选择灌装数量确定灌装头数。
触摸式操作彩屏，可显示生产状况、操作程序、灌装方式等。画面直观、操作简单、维护方便。
每个灌装头设有卡瓶口设置、确保注料对位准确。
二、独特的灌装方式
设计选用直线式分组进瓶、出瓶的方式、使灌装功能扩展，各种形状的容器、都能在本设备有效灌装。
选用国际先进的气体灌装阀，确保灌装过程无滴漏、无垂涎。
强大的PLC软件支持，可实现理想的灌装作业。
人机友好界面，所有操作均在触摸式彩屏上完成。
三、**的计量控制
灌装采用固定流道参数，控制灌装时间来实现不同计量的灌装。
气动阀灌装的**时间可设定到0.01秒，能使计量**度控制在±1%误差范围，减少不必要的物料损耗，提高用户经济效益。
每个灌装头的计量可以进行单独调整，以实现灌装计量的一致。
本机设定了进瓶技术程序、无瓶、计数不到位不灌装，只有当计数器记录到的瓶数与设定的灌装瓶数一致时才开始灌装。
灌装量的多少，可以进行初调到所需灌装量时，再进行微调，即可得到理想的灌装计量精度。
四、技术参考
序号 | 型 号 | ZHGA-2 | ZHZA-4 | ZHGA-6 | ZHGA-8 | ZHGA-10 | ZHGA-12 |
1 | 灌装头数 | 2 | 4 | 6 | 8 | 10 | 12 |
2 | 灌装容量 | 100－10000ml | |||||
3 | 生产能力(瓶/小时) | 350-500 | 600-1000 | 1000-1500 | 1500-2200 | 1600-2200(5L瓶计) | 1800-2600 (5L瓶计) |
4 | 灌装精度 | ≤0.5% | |||||
5 | 电 源 | 50HZ/60HZ 3N-380V 土 10％ | |||||
6 | 功 耗 | 0.75KW-7.5KW | |||||
7 | 配用气源压力 | 0.5-0.8MPa | |||||
8 | 工作压力 | 0.6-0.7MPa | |||||
| |||||||
四川省邛崃市四信灌装机销售中心是一家专业销售、安装、维修食用油灌装机、酒水、饮料、油类及酱油、醋等液体灌装机的企业。四信灌装机销售中心技术专业、服务优良、客户遍布四川、湖北、贵州、广州、新疆、西藏各省。主导产品有高精度灌装机，烘干机，气动旋盖机，食用油灌装机及其他油类灌装机械，直列式微电脑灌装机等。产品质量可靠，操作简单，定量准确，工作效率高，符合**标准，适合各种瓶型，是大、中、小企业理想的生产设备。
“诚信、守信、信心、自信”是四信灌装机销售中心的经营宗旨。我们一贯秉承着“四信”的经营作风，为每一位客户提供方便快捷**的服务和**的灌装机及灌装设备产品。所有设备保修壹年，配件常年供应。
本部坚信“只有良好的信誉和服务，才能保证长久的销售”欢迎各界新老客户前来洽谈业务。
This machine is one kind by the microcomputer (PLC) programmable control, the photoelectricity sensing, the air operated execution fills in a body high technology and new technology installs the equipment. The this aircraft uses in food class specially, for example: White liquor, soy sauce, vinegar, seasoning, vegetable oil, syrup, mineral water and so on edibility the liquids as well as the agricultural chemicals chemical industry class liquid fills the attire. Fills installs the measurement to be precise, does not have the air bubble, does not have the dripping of a water clock. Suitably (including leads bottle) fills the attire in 50-1000ml each kind of bottle.
①The advanced design
this machine is suitable in the different specification vessel fills the attire, may cut in several minutes fills installs the specification.
Fills installs the cycle short, productivity is high.
The replacement fills installs the specification not to need to increase the spare parts, only must make the adjustment then to complete.
The user may act according to own productivity choice to fill installs quantity to determine fills the pattern number.
The touching type operation colored tablet, may demonstrate the production condition, the operation sequence, fill install the way and so on. The picture direct-viewing, the operation simple, the maintenance is convenient.
Each fills the pattern to be equipped with the card bottle mouth establishment, to guarantee the note material to be accurate to the position.
②Unique fills installs the way
design to select the straight line type to group the bottle, the bottle way, causes to fill installs the function to expand, each kind of shape vessel, all can fill the attire effectively in this equipment.
Selects the international advanced gas to fill installs the valve, guarantees fills installs the process not to have the dripping of a water clock, not to drool.
The formidable PLC software support, may realize ideally fills installs the work.
The man-machine friendly contact surface, all operations complete on the touching type colored tablet.
③The precise measurement control
fills the attire to use the fixed flow channel parameter, the control fills installs the time to realize the different measurement to fill the attire.
The pneumatic valve fills the precise time which installs to be possible to establish to 0.01 second, can cause the measurement precision control at±1% erroneous scope, reduces the nonessential material loss, enhances the user economic efficiency.
Each fills the pattern the measurement to be possible to carry on the independent control, realizes fills installs the measurement the consistency.
The this aircraft established has entered the bottle technology procedure, does not have the bottle, the counting does not arrive does not fill the attire, only then when the counter recorded the bottle number filled the bottling number consistently with the hypothesis when only then starts to fill the attire.
Fills the load how many, may carry on when initially moves must fill the load, again carries on the trimming, then obtains ideally fills installs
④The technical reference
fills installs the scope 50~1000 milliliters
to fill installs the speed <90 bottle/The minute (refers to 100~500 milliliters scopes)
to measure the precision±1%
rated power 0.8 kilowatt
working voltage 220 volt
work barometric pressure 6~7 kilograms/Square centimeter
gas consumption 0.5 cubic meter/Minute
machine net weight 650 kilogram
external dimensions 2000×870×1900 millimeter
